At the Grundfos Product Center, you can quickly and easily find pump installation guides, pump manuals, and all the technical data you need to keep your system working its best. Step 1: Go to Grundfos Product Center. Once you enter Grundfos Product Center, you will see a menu with four colored categories at the top. Select 'Catalog'.. The pump can be installed indoors or outdoors, but it must not be exposed to frost. We recommend that you install the pump near a drain or in a drip tray connected to a drain in order to lead away possible condensation from cold surfaces. 3.1.1 Minimum space The pump requires a minimum space of 430 x 215 x 325 mm (17 x 8.5 x 12.8 inches).
the pump in the pipe. Install the pump with a horizontal motor shaft within ± 5 °. See fig. 2. See also section 3.3 Control box positions. 3. Tighten the fittings. See fig. 3. Fig. 1 Flow direction Fig. 2 Pump installation Observe these instructions for explosion-proof products. A blue or grey circle with a white graphical symbol. installing the pump. 2. Do not install the pump at the lowest point of the system where dirt and sediment naturally collect. 3. Install a vent at the high point(s) of the system to remove accumulated air. 4. Ensure that water does not enter the terminal box during the installation process. 5. Open system: Install the pump in the supply
